Rugged Tablet PC-SR800


Compact A4 size with bumper and Magnesium-Alloy Housing in high strength and rugged structure
Ideal size 10.4" XGA (1024x768) TFT with resistive touch screen/digitizer, outdoor readable
Intel Core Duo Processor Yonah Ultra Low Voltage 1.2GHz Processor
Built-in WiFi 802.11 a/b/g; Bluetooth 2.0 Class I; CF/ PCMCIA card slots to support UMTS/HSDPA/EDGE/ GPRS/GPS Card
Meet IP54 standard and compliant MIL-STD-810F
Wide temperature range operation (-20°C~ +60°C)
7 hours of long operating battery life
RS232 port for industrial device connection



Features:

RUGGEDBOOK Tablet PC SR800 takes the best aspects of the tablet PC technology and improves it for high-performance mobile applications. Ideal industries are field service, public safety, construction, logistics, law enforcement, military, social welfare, transportation, health care, and hospitality.
SR800 is designed to meet the mobile computing needs and form-factor requirements of on-the-go professionals. Moreover, the rugged design of IP54 can resist against various conditions such as shock, vibration, spill, dust and dirt, hot, and damp. In addition, the magnesium enclosure is employed especially for harsh environments and physical stresses.
Features of SR800 are mid-sized, lightweight, ergonomic, and multiple integrated wireless technologies which includes EDGE/GPRS, 802.11 a/b/g, Class I Bluetooth, and GPS. Therefore, it has compatibility with any wireless network.
To sum up, SR800 is an ideal solution to reduce the damage, failure rate, overall cost, and dependence on wired desktops for data and application access. Moreover, SR800´s rugged nature provides the highest protection, productivity, profitability for both indoor and outdoor environment.


Specifications:
CPU

Intel® Core Duo 1.2GHz (U2500) CPU
Intel® 945GME chipset

LCD Panel

10.4” XGA (1024x768) TFT LCD with resistive touch control panel
Optional: Outdoor readable display
Optional: Dual mode resistive & digitizer touch panel

Memory & Storage

1GB RAM (up to 2GB max)
Shock proof mounted, 2.5” 250GB HDD

Audio Internal microphone and speaker
Interface

2 x USB 2.0 port
1 x Mini USB 2.0 port
1 x RS-232 port
1 x DC-In jack
1 x Microphone
1 x Earphone
1 x RJ-11
1 x RJ-45
1 x Docking connector

Expansion Slots

1 x PCMCIA Type II slot
1 x Compact Flash Type II slot

Buttons

Five-way control key and four button key
Reset button
Digitizer/ resistive Switch
Power button
WiFi /BT switch
Screen Rotate hotkey
Function hotkey
SAS/ESC

Wireless

Integrated WiFi 802.11 a/b/g
Bluetooth 2.0 Class I + EDR

Power Supply

Input: 100V-240V, 50-60Hz
Output: 20V/65W
Li-Ion Battery 7200mAh
Max. 7 hours in normal usage

Software Windows XP Tablet PC Edition
Durability Features IP54, MIL-STD-810F

Operating Temperature

Operating:-20℃ to + 60℃;
Storage: -20℃ to +70℃
Cold boot: 0℃(battery >75o/o charge)

Dimension & Weight

284 x 209 x 63 mm
2.2 kgs

Certification

CE
FCC
TUV
cUL
CB
BSMI

Accessories

Power adapter
Power cord
Stylus
Service DVD

Warranty 1yr up to 3yrs limited warranty










BR668VHMT011

BR800PURA010

VR6680100069


VR8000100017

V7178GPS-SAM

VR8000000004


VR8009510001

MR6685020001

BR668CARY010


M56221010002

VR668BAT0001

BR668BELT010


VR6680100094

BR6680000010

BR668CFPC010


VR8009530001

AR800001-SAM


Field Service
Government
Construction & Manufacturing

Transportation
Logistics
Hospitality

Retailing
